View larger

Online only

WINTEC - LP-4502 - + PMR-446 radio

Reference: LP-4502

Condition: New product

New version Wintec LP-4502 + 16 channels pre-programmed (incl the new & old PMR-446 frequencies)

Incl. fast charger (stand charger) & 1500mAh high-performance battery at a special price

More details

By buying this product you can collect up to 1 loyalty point. Your cart will total 1 loyalty point that can be converted into a voucher of 1,00 €.

Pay it by wire
and save an additional 1,10 €

More info

WINTEC LP-4502 + PMR-446 two-way radio

The compact and robust housing shape distinguishes the LP-4502. The polycarbonate housing has a textured surface and lies securely in the hand.

The standards IP54, IP55 and US-MIL-STD 810 C, D, E are met, so resistance to rain, moisture, dust, vibration and shock is given.

The LP-4502 enables secure communication for both indoor and outdoor use.

Technical specifications

channels	16 preprogrammed
Transmission power	500 mW
Frequency range	446.00625 - 446.19375 MHz
Features & functions	51 different pilot tones (CTCSS) and 104 DCS pilot tones VOX function adjustable in 8 sensitivity levels (voice-controlled transmission) Scrambler, voice encryption (can only be activated via software - option) SCAN Automatic fast channel search for channels and CTCSS pilot tones SOS emergency channel function, freely programmable Dual-Watch - two-channel monitoring MEMORY 1 memory channel can be saved as required TONECALL You can define up to 7 different tones as you like and can therefore also determine the acoustics of call participants Semi-duplex function allows transmission on one channel to be received on another channel Roger Beep can be activated 8-digit digital S-meter in the display Volume adjustable in 16 levels Switchable keyboard lock Keypad acknowledgment tones (can be switched off) backlit LC display optical battery level indicator and acoustic warning tone adjustable squelch and monitor circuit Degree of protection according to IP54, IP55 and US-MIL-STD 810 C, D, E
Connection for external audio accessories	WINTEC standard 2.5 / 3.5mm double jack sockets on the side of the device
Power supply	7.2V DC with the battery packs BT-FR-80 / BT-FR-80-LI 12V DC with the car adapter BT-FR-80C
Dimensions (mm), WxHxD	55 x 95 x 31 (height with antenna 200 mm)
Weight	approx. 250g (including battery pack)

Scope of delivery
Wintec LP-4502 + radio
BT-FR-80-LI battery pack (1500mAh, Li-Polymer)
fast charger (floor charger) L-CHG-81-B
power
adapter for charging cradle Belt clip
cover for Sp./Mic. Socket
Instructions
Weight: 0.25 kg
