ALAN - 42-DSMULTI - Multi Channel CB Handheld

Midland presents the new version of the ALAN 42 model

The portable CB transceiver ALAN 42 DS.
It is equipped with digital squelch and ANL filters and Noise Blanker that eliminate disturbances caused by external sources or by the vehicle.
ALAN 42DS maintains the same functions as the former Alan 42: it is a multistandard device that allows you to select any European band and operate in all EU countries. The digital squelch is the automatic squelch regulation that avoids the use of manual regulation; it is automatically activated according to the received input signal; the Noise Blanker and ANL filters, on the other hand, improve the sound and make it cleaner, eliminating disturbances caused by external sources or by the vehicle, such as ignition noise. Among the various functions it is equipped with, we report the EMG function for the immediate selection of the emergency channel, the high and low power (4W / 1W) selectable, the SCAN and Dual Watch functions.

FEATURES:

• Band: Multi (See specific table, page 31)
• Power: 1W/4W depending on the country
• Emergency channel (EMG)
• Keypad lock (LOCK)
• Battery state indicator
• High-lower power (H-L)
• Display back-lighting button
• AM-FM command selection
• SCAN function, Dualwatch
• Antenna socket: BNC
• Powered by 8 AA batteries or 12V
• 2-pin accessory socket

  PACKAGING:
• 1 radio Aalan 42ds
• Wall charger for 8 style battery pack,
• 1x Empty battery pack for 6 styles type alkaline AA
• 1x Empty battery pack for 8 type AA styles for rechargeable batteries with charging socket.
• 1x Adapter for car use with external SO 239 antenna socket
• 1x Scratch-resistant case
• 1x Antenna
• 1x Belt clip
• 1c Wrist strap

  Technical specifications
• Channels : 40 FM (see the Frequency band chart)
• Frequency Range*: 26.565 - 27.99125 MHz
• Operating mode: F3E (FM), A3E (AM).
• Antenna impedance: 50 Ohm.
• Loudspeaker: 8 Ohm 0.5W.
• Microphone: condenser type
• Power supply: min 7.2Vdc;max 13,8Vdc; nom 12,6Vdc
• Dimensions: 30x70x140 mm.
• Weight: 220 gr. (without batteries).
  RECEIVER
• Sensitivity at 10dB S/N: 0.5μV (AM), 0.25μV (FM)
• Selectivity: more than 60dB
• Squelch range: 0.25V-500μV
• Audio output power: 0.5W 8 ohm (10% distortion)
• Distortion at 1000 μV: 3%
• Audio frequency response: 400-2400 Hz
• Intermediate frequency: I° 10.695 MHz/ II° 455 KHz
• Spurious response: more than 60 dB
• Current drain at stanby: 100 mA when the save mode is off / 45 mA when the save mode is on
  TRANSMITTER
• RF Output Power: duty cycle 10% 4W AM/FM
• Frequency Tolerance: 0.005%
• Harmonic Suppression: more than 70 dB
• Current Drain: 900 mA
  Modulation: AM 90% (} 5%) / FM dev. 2.0KHz
  * (covering all approved EU frequency bands)
  Specifications are subject to change without notice.
  WARNING: Direct plug-in ac/dc power supply must be used for disconnecting the transceiver
  from the mains; the desktop charger must be positioned close to the unit and easily accessible.
